Gedore Torque wrench DREMOMETER DZ 22Z 140-620 Nm 7703020
Classified to DIN EN ISO 6789:2003 Type II Class A, with a factory certificate. Working accuracy: +/- 3 % tolerance of scale set torque. The specification of the standard (+/- 4 %) is exceeded. • Lightweight yet robust (as the housing is made of an aluminium alloy) and resilient, very workshop-friendly • Depending on the application, access is possible from the front (e.g. open-end fitting) or side (e.g. reversible ratchet and socket) • Force to be applied in the middle of the handgrip only - do not use an extension tube as otherwise, inaccuracies can evolve (except for model DXZ where the DREMOMETER has been calibrated and adjusted using the extension tube) • Operation only with end fittings with standardised depth gauges, otherwise inaccuracies can arise. Keep the depth gauges on the certificate in mind. Only use original GEDORE accessories. • Large drive cross-section transfers maximum torques • Extremely low wear attributable to reduced forces in the lever mechanism • Forged lever chain from our own quality forge • Maximum precision even when subjected to extreme continuous use • Long life cycles and tool lives • Easy operation - fast and safe torque tightening • Easy adjustment thanks to attractive adjusting button secured against loss at the end of the handle • With certificate acc. to DIN EN ISO 6789, traceable via in-house DAkkS laboratory to national standards
- Drive Type: DZ
- Drive connector pin: 22
- Range of work / measurement N.m (min/max): 140-620
- Range of work / measurement lbf.ft (min/max): 100-450
- Scale divisions: 10 N·m / 10 lbf·ft
- Distance middle of handgrip to pivot point: 767,5
- Depth gauge (C, L): 56
- Width: 45
- Distance middle of screw to pivot point: 49
- Distance housing - drive: 17,5
- Length (L, L1): 846
- Weight: 3,000
