Gedore Reaction arm Z-form offset for DVV80 2653206
Particularly suitable for: • Machinery and plant engineering • Cable cars, lifts and masts • Heavy industry, construction sites • Bridge construction • Shipbuilding, aircraft and railway construction • Refineries, plastics industry • Power plants of all kinds Features: • Mechanical hand torque multiplier for controlled screw tightening and unloosening screw connections • With a two-stage planet gear • High-performance aluminium housing • Torque multiplication ratio: 1:18, 1:22, 1:28.5, 1:39 • All models with anti-wind-up ratchet (RS) • With non-destructive "Slipper" overload safety mechanism for gear protection - clockwise and anticlockwise • Z-form, offset reaction arm depending on model made of chrome-vanadium steel • Can be optionally retrofitted with L-form straight reaction arm - with adjustable reaction arm - of lightweight metal • Guaranteed accuracy: Better than +/- 3 % tolerance • For operation in combination with a torque wrench • 4 models for maximum load in the range between max. 6000 N·m and max. 13000 N·m • Output square with drill hole for impact sockets with safety pin and ring Scope of delivery: • Torque Multiplier DREMOPLUS ALU • With Z-form offset reaction arm • Delivery in sturdy shipping case with foam insert • Factory test certificate and setting table • Detailed technical information is available on request
- Packing Unit:- 1 Piece
- Distance from Drive to Beginning of Reaction Arm (min.):- 110 mm
- Distance from Drive to End of Reaction Arm (max.):- 190 mm
- Weight:- 4.3 kg
- Width of Torque Multiplier:- 128 mm
- Height of Torque Multiplier:- 277 mm
