Please note images are standard tools
Benefits
Best performer for Industrial Maintenance & Production applications
Operator comfort and control even on high torque
Reliable double-dog clutch in oil bath & durable housing
Compact 3-part construction for easy maintenance
Features
1/2" industrial impact wrench with Pin-type socket retainer
CP's patented double dog clutch with oil bath
Aluminium body & steel clutch housing
Regulator 4 settings & One-hand reverse
Comfortable handle with rubber grip
Stainless steel attachment point
Metric Imperial
Actual air consumption 11.8 l/s 25 cfm
Air inlet thread size 1/4 "
Blows per minute 1320
Clutch type SpringHammer™ Double dog - Oil bath
Free speed 6400 rpm
Handle type Pistol
Length 178 mm 7 "
Maximum Torque (reverse) 850 Nm 625 ft.lbs
Net weight 2.65 kg 5.8 lb
Power/weight ratio 320.8 Nm/kg 107.8 ft.lb/lb
Side to center 32 mm 1.26 "
Socket retainer Pin
Sound Power 107 db(A)
Sound pressure 96 db(A)
Square drive 1/2 "
Vibration 8 m/s²
Vibration uncertainty (K) 2 1/2 m/s²
Vibration-ISO ISO-28927-2
Working Torque Range (fwd) 170 - 680 Nm 125 - 502 ft.lbs
